CS Nano Slim


CS Nano Slim

(Aluminum Nano Slim)

Nano slim looking door made up of 34mm glass and has a full fix glass to have a look into. The profile of the two-sash equal none. There is no difference in strength and to watch the view of one outside. It is the best system and gives an architect look. Is also featured with super multi lock system. Another appealing thing about it is, its smooth and easy sliding. It also takes care of the security system and the locking has a luxury handle.

Feature Specification
Sight Line / Face Width 17 mm
Section Joint ‘L’ Clamp Fitting with Grub Screws
Sash Degree 90 Degrees Machine Precision
Glass Thickness 34 mm
Sliding Rail Stainless Steel-316
Sash Degree 90 Degrees Machine Precision
Roller Bearings SS-316, 200 per Bearing
Coating Powder Coating / PVDF / Anodized
Handle 180 Degrees
Maximum Shutter Size 4.3 sq m
Maximum Shutter Height 4.2 m
Wind Resistance Up to 2.8 kPa
Air Penetration 300 Pa
Water Penetration 300 Pa
