CS Ultra Slim


CS Ultra Slim

(Aluminum Sliding Slim Door)

Company offers turn - key services and systems which have been brought from the european market in designing, manufacturing, installation and exporting its finished aluminium product to the building industry such as luxury villas and bungalow having a full glass house and from where outside view is easily accessible. The main objective of the elevation is to give large and extravagant look. There is multi lock system in it which combines the latest security and protection features with user friendly comfort and elegant designs and it also has an impact wheel that will last longer.

Feature Specification
Sight Line / Face Width 18 mm
Section Joint ‘L’ Clamp Fitting with Grub Screws
Sash Degree 90 Degrees Machine Precision
Glass Thickness 34 mm
Sliding Rail Stainless Steel-316
Sash Degree 90 Degrees Machine Precision
Roller Bearings SS-316, 200 per Bearing
Coating Powder Coating / PVDF / Anodized
Handle 180 Degrees
Maximum Shutter Size 4.3 sq m
Maximum Shutter Height 4.2 m
Wind Resistance Up to 2.8 kPa
Air Penetration 300 Pa
Water Penetration 300 Pa
